Characteristic:
1) X,Y axises adopt gear-wheel, speed is fast. It adopts domestic no oil vaccum pump
with high efficiency.
2)Adopt Japan yaskawa servo motor ,built-in encoder,It can stop automatically when graunch happens,so can avoid accidents .
3)Whole machine is welded with seamless steel structure, the regidity is good , not easy to be deformed.The gantries adopt steel
structure
4)All adopt imported square oribit, heavy loading, stable working , high precision and long lifetime. Imported ballscrew , high
precision.

5).With 4 cylinder and 2 Pressure wheel for fix the material.

Performance parameter:

Description	parameter
XYZ working area	1300*2500*200mm	1500*3000*200mm	2000*3000*200mm
Table size	1440X3040mm	1640*3540mm	2140*3540mm
X,Y,Z Traveling Positioning Accuracy	±0.03/300mm
X,Y,Z Repositioning Positioning Accuracy	±0.01mm
Lathe Structure	Welded Strucutre
X, Y Structure	Gear Wheel Transmission, Shaft Linear Bearings
Z Structure	Ball Screw, Shaft Linear Bearings
Max.Consume Power	20KW
Max.Speed	0-60000mm/min
Max.Working Speed	0-25000mm/min
Spindle Power Motor	5.5 or 7.5Kw  spindle
Spindle Speed	0-24000RPM
Working Mode	Servo system
Working Voltage	AC380V/50/60Hz , 3PH
Command	G Code, *uoo, *mmg, *plt
Operating System	SYNTEC or Weihong System
Interface	Internet line
Flash Memory	512M
Collet	ER32
X,Y Working Delicacy	<0.01mm
Software	Type3 software, Wentai software,Artcam software
Running circumstance	Temperature: 0°C~45°C, Relative humidity: 30%~75%
Packing Size	4000x2150x2200 mm
Net Weight	2000KG
Gross Weight	2300KG

Working Samples:
