Applicable industries:

Balustrade,furniture legs,stair railing ,cylinder items,handrail,desk or chair legs,teatray,The human body,avatar,3D cylinder mold,and a variety of rotational symmetry.
Wood processing:processing of various furniture such as door, window, cabinet, furniture, craft wood door, screen and so on.

Applicable materials:

Wood, aluminum board, plastic, density board, wave board, PVC, acrylic, crystal, light marble and other nonmetal materials and light metal materials.

Processing effect:

It can manufacture the following effects: engraving, cutting, milling, drilling, relief, shadow, enchase and so on.

Technical Parameter

Description	Parameter
X,Y,Z Effective Working Table Area	2400mm*1500mm*300mm
Rotary Max.Diameer	300mm
Rotary Max.Length	1500mm
Table Size	2140mm*3400mm
Resolution	0.03mm
Lathe Structure	Seamless welded steel structure
X,Y Structure	Rack and pinion transmission, Hiwin square guide rail
Z Structure	Germany rolling ball screw, Hiwin square guide rail
Max. Idling Speed	35m/min
Single Spindle Power	2.2 KW water cooling spindle
Spindle Rotate Speed	0-24000r/min, variable speed
Working Voltage	AC380V/50Hz
Working Mode	Servo
Command	G code (HPGL,U00,mmg,plt)
Operating System	DSP/NC Studio/Mach3
Diameter of cutter	φ3.175-φ12.7mm
Dust-collect Function	Yes
Work-holding	By clamp
Software	Type 3, ArtCam,powermill, Wentai
Packing size	3900mm*2280mm*2260mm
Net Weight	2300KG

Machine Parts：





















































































Working Samples：

















































Producing Process：























































































































































Company Profile：







































































































































FAQ：

Q1.How to get the most suitable machine and best price

Please tell the material you want to working on ?

How to working on it ? Engraving ? Cutting ? Or other ?

What’s the MAX size of these material ?( length ? Width ? Thickness ?)

Q2.What is the payment?

The payment is 30% or 50% T/T or Alibaba trade assurance in advance, balance after machine finished.

Q3.What is the producing time after order?

The proucing time is about 10-20 days depend on different machines.

Q4.If we don’t know how to use the machine,can you teach us?

Yes,we will ,if you come to China,we will offer you free training until you can use machine freely.And if

you are busy ,we will have the special engineer to your country,but you need to bear some fee,like

tickets and hotel and meal.

Q5.How about your after-sales service?

we offer you 24 hours service phone,skype or whatsapp, our engineer also can go to door install or training.

Q6. Quality Control:

The whole production procedure will be under regular inspection and strict quality control. The complete machine will be tested to make sure they can work very well before being out of factory.

The testing video and pictures will be available before delivery.
